Product Detail

Front Terminal Battery Series

The Front Terminal Series is specially designed for telecommunication use with 15+ years design life in float service. By combining the newly developed paste formula with up-to-date AGM structures, this range features 15 years design life and Front Terminal connection for fast, easy installation and maintenance. This series is highly suited for telecom applications, UPS systems

Summary
Sealed and Maintenance-free Operation
High Quality and High Reliability
Exceptional Deep Discharge Recovery
Low Self-discharge
Long Service Life
Solid Copper Terminals
Tank-formed Plates
Computer-aided Design and Manufacturing
UL,CE Approved


Typical Applications
UPS systems
Electronic instruments
Solar power system
Wind Power system
Telecommunication equipment


Description


Model

Nominal Voltage(V)

Capacity   (10Hr/Ah)

Dimension(mm)

Terminal

Weight ±3%(Kg)

Length

Width

Height

Total height

Type

Position

HX12-50FT1250277106221221F14215.5
HX12-75FT1275562114189189F14224.5
HX12-100FT12100506110224239F14231
HX12-100AFT12100395110286286F14231
HX12-110FT1211033
HX12-120FT12120551110239239F13236
HX12-125FT12125436108317317F13237

HX12-150FT

12150551110287287F13248
HX12-180FT12180560126316323F13256
