OPzS Battery Series

The OPzS series is a traditional tubular plate flooded battery which offers 20+ years design life according to the standard IEC60896-11.With a new design and technical improvement, it offers maximum efficiency and reliability for the widest variety of applications. This series is highly suited for all standby power applications that require the highest levels of reliability and security

Summary
The OPzS series stationary batteries are the newly products which were developed at the middle of 2006.The performances meet the standard DIN40736 and IEC60896-21

Typical Applications
UPS power supply
Electronic instruments
Wind Power system
Fire alarm and security device
Solar Power system
Telecommunication equipment


Description


Model      Rated Voltage (V)

Rated Capacity

Dimension（mm）      Terminal      Weight ±3%(Kg)
Length      Width      Height      Total height      Type      Dry      Wet
OPzS2-1002100103206355410F128.513.5
OPzS2-1502150103206355410F121115.5
OPzS2-2002200103206355410F1213.517.5
OPzS2-2502250124206355410F121621
OPzS2-3002300145206355410F1217.524
OPzS2-3502350124206471526F122128
OPzS2-4202420145206471526F122332
OPzS2-5002500166206471526F122636
OPzS2-6002600145206646701F123143
OPzS2-8002800191210646701F124460
OPzS2-100021000233210646701F125272
OPzS2-120021200275210646701F126286
OPzS2-150021500275210796851F1275105
OPzS2-200022000397212772827F12108150
OPzS2-250022500487212772827F12130183
OPzS2-300023000576212772827F12157220
